From November 18–21, Tichawa Vision will be exhibiting at SEMICON Europa in Munich. In Hall C1, Booth 643, we will be presenting the innovative high-resolution BergKristall WaferCIS. Visitors are cordially invited to learn about the technology and exchange ideas on site.
BergKristall live demo at SEMICON Europa 2025
At SEMICON Europa 2025, Europe’s largest electronics platform, our experts will be presenting the innovative features of the BergKristall WaferCIS at the joint Tichawa Vision and ISDI booth C1643. Live demos, insights into customized solutions, and concrete application examples will give visitors a clear impression of the technical features of this innovation from Germany.
BergKristall WaferCIS – for demanding users
With the BergKristall sensor, Tichawa Vision presents a high-resolution wafer inspection solution with flexible lighting and synchronized front and back inspection. In addition, the BergKristall Wafer-CIS enables seamless inspection processes with RGB and IR lighting, high dynamics, fast imaging, and flexible scan width.
The BergKristall-CIS has numerous features that make it easy to use.
The WaferCIS is a scanning system that enables RGB imaging with a sampling rate of 6 kHz and a scanning speed of 64 mm/s. It delivers 12-bit amplitude resolution with up to 4000 grayscales per color, achieving a dynamic range of
Two functions are integrated to ensure consistent image quality:
- DSHR technology, which reduces banding effects
- 2 MB shading memory, which allows the shading table to be quickly adjusted
The depth of field of ±0.5 mm ensures that even slightly uneven surfaces can be captured.
Illumination and flexibility
The system supports various light sources:
- diffuse illumination
- coaxial illumination
- optional IR illumination (860/940 nm)
The scan width is flexible:
- 220 mm for 8-inch wafers (3 × 21,000 pixels RGB or 4 × 21,000 pixels RGB+IR)
- 330 mm for 12-inch wafers (3 × 31,000 pixels RGB or 4 × 31,000 pixels RGB+IR)
Conclusion
The BergKristall WaferCIS from Tichawa Vision combines high resolution, flexible lighting, and precise inspection functions in a single system. The combination of RGB and IR lighting, fast imaging, and flexible scan width enables reliable inspections even on uneven surfaces.
Live demonstrations and practical application examples at SEMICON Europa 2025 will offer visitors the opportunity to see the technical features and performance of this innovation made in Germany for themselves.
We look forward to seeing you at our booth in Hall C1, Booth 643, and to a constructive and exciting exchange and networking opportunity.
Make an appointment: kontakt@tichawa.de
